ControlNet Preprocess Canny

May 1, 2025

ControlNet Preprocess Canny converts an input image into a high-contrast Canny edge map for ControlNet conditioning. It is best suited to workflows that need clear object boundaries, strong silhouette retention, and tightly constrained structure during guided image generation or editing.

Preprocess

Porcelain Tea Service Arrangement

import { createClient } from '@runware/sdk'

const client = await createClient({ apiKey: process.env.RUNWARE_API_KEY })
await client.connect()

const [result] = await client.run({
  model: 'runware:controlnet-preprocess@canny',
  settings: {
    lowThresholdCanny: 70,
    highThresholdCanny: 190
  },
  inputs: {
    image: 'https://assets.runware.ai/assets/inputs/fee1a1d5-d8f1-4224-a7d7-44bb8f29f591.jpg'
  }
})

import asyncio
import os

from runware import Runware


async def main():
    async with Runware(api_key=os.environ["RUNWARE_API_KEY"]) as client:
        results = await client.run({
            "model": "runware:controlnet-preprocess@canny",
            "settings": {
                "lowThresholdCanny": 70,
                "highThresholdCanny": 190
            },
            "inputs": {
                "image": "https://assets.runware.ai/assets/inputs/fee1a1d5-d8f1-4224-a7d7-44bb8f29f591.jpg"
            }
        })


asyncio.run(main())

curl https://api.runware.ai/v1 \
  -H "Authorization: Bearer $RUNWARE_API_KEY" \
  -H "Content-Type: application/json" \
  -d '[
    {
      "taskType": "controlNetPreprocess",
      "taskUUID": "3168ff38-89cd-449b-8695-7f0df51af21f",
      "model": "runware:controlnet-preprocess@canny",
      "settings": {
        "lowThresholdCanny": 70,
        "highThresholdCanny": 190
      },
      "inputs": {
        "image": "https://assets.runware.ai/assets/inputs/fee1a1d5-d8f1-4224-a7d7-44bb8f29f591.jpg"
      }
    }
  ]'

runware run runware:controlnet-preprocess@canny \
  settings.lowThresholdCanny=70 \
  settings.highThresholdCanny=190 \
  inputs.image=https://assets.runware.ai/assets/inputs/fee1a1d5-d8f1-4224-a7d7-44bb8f29f591.jpg

{
  "taskType": "controlNetPreprocess",
  "taskUUID": "3168ff38-89cd-449b-8695-7f0df51af21f",
  "model": "runware:controlnet-preprocess@canny",
  "settings": {
    "lowThresholdCanny": 70,
    "highThresholdCanny": 190
  },
  "inputs": {
    "image": "https://assets.runware.ai/assets/inputs/fee1a1d5-d8f1-4224-a7d7-44bb8f29f591.jpg"
  }
}

Response

{
  "taskType": "imageControlNetPreProcess",
  "taskUUID": "3168ff38-89cd-449b-8695-7f0df51af21f",
  "guideImageURL": "https://im.runware.ai/image/os/a08dlim3/ws/3/ii/7dfa23da-ce7d-4d7b-88e5-52e83c3d36a8.jpg",
  "cost": 0.0006,
  "guideImageUUID": "7dfa23da-ce7d-4d7b-88e5-52e83c3d36a8",
  "inputImageUUID": "681ec270-83c0-451d-a4db-12b455df00d9"
}

Preprocess

Mechanical Peacock Tail Blueprint

import { createClient } from '@runware/sdk'

const client = await createClient({ apiKey: process.env.RUNWARE_API_KEY })
await client.connect()

const [result] = await client.run({
  model: 'runware:controlnet-preprocess@canny',
  settings: {
    lowThresholdCanny: 50,
    highThresholdCanny: 160
  },
  inputs: {
    image: 'https://assets.runware.ai/assets/inputs/92f673cc-2c3c-41fb-b3a5-c4a29fb863ff.jpg'
  }
})

import asyncio
import os

from runware import Runware


async def main():
    async with Runware(api_key=os.environ["RUNWARE_API_KEY"]) as client:
        results = await client.run({
            "model": "runware:controlnet-preprocess@canny",
            "settings": {
                "lowThresholdCanny": 50,
                "highThresholdCanny": 160
            },
            "inputs": {
                "image": "https://assets.runware.ai/assets/inputs/92f673cc-2c3c-41fb-b3a5-c4a29fb863ff.jpg"
            }
        })


asyncio.run(main())

curl https://api.runware.ai/v1 \
  -H "Authorization: Bearer $RUNWARE_API_KEY" \
  -H "Content-Type: application/json" \
  -d '[
    {
      "taskType": "controlNetPreprocess",
      "taskUUID": "e3cddd6d-b206-4724-b34d-2a3af7ad8e81",
      "model": "runware:controlnet-preprocess@canny",
      "settings": {
        "lowThresholdCanny": 50,
        "highThresholdCanny": 160
      },
      "inputs": {
        "image": "https://assets.runware.ai/assets/inputs/92f673cc-2c3c-41fb-b3a5-c4a29fb863ff.jpg"
      }
    }
  ]'

runware run runware:controlnet-preprocess@canny \
  settings.lowThresholdCanny=50 \
  settings.highThresholdCanny=160 \
  inputs.image=https://assets.runware.ai/assets/inputs/92f673cc-2c3c-41fb-b3a5-c4a29fb863ff.jpg

{
  "taskType": "controlNetPreprocess",
  "taskUUID": "e3cddd6d-b206-4724-b34d-2a3af7ad8e81",
  "model": "runware:controlnet-preprocess@canny",
  "settings": {
    "lowThresholdCanny": 50,
    "highThresholdCanny": 160
  },
  "inputs": {
    "image": "https://assets.runware.ai/assets/inputs/92f673cc-2c3c-41fb-b3a5-c4a29fb863ff.jpg"
  }
}

Response

{
  "taskType": "imageControlNetPreProcess",
  "taskUUID": "e3cddd6d-b206-4724-b34d-2a3af7ad8e81",
  "guideImageURL": "https://im.runware.ai/image/os/a03d21/ws/3/ii/0ffe6036-e273-4eef-981b-5e35c5fbebb1.jpg",
  "cost": 0.0006,
  "guideImageUUID": "0ffe6036-e273-4eef-981b-5e35c5fbebb1",
  "inputImageUUID": "763e276a-91c1-4192-a995-0e8f9b608649"
}

Preprocess

Ornate Pipe Organ Facade

import { createClient } from '@runware/sdk'

const client = await createClient({ apiKey: process.env.RUNWARE_API_KEY })
await client.connect()

const [result] = await client.run({
  model: 'runware:controlnet-preprocess@canny',
  settings: {
    lowThresholdCanny: 80,
    highThresholdCanny: 190
  },
  inputs: {
    image: 'https://assets.runware.ai/assets/inputs/fe5e44a9-08e9-45be-9295-5cc443b3be06.jpg'
  }
})

import asyncio
import os

from runware import Runware


async def main():
    async with Runware(api_key=os.environ["RUNWARE_API_KEY"]) as client:
        results = await client.run({
            "model": "runware:controlnet-preprocess@canny",
            "settings": {
                "lowThresholdCanny": 80,
                "highThresholdCanny": 190
            },
            "inputs": {
                "image": "https://assets.runware.ai/assets/inputs/fe5e44a9-08e9-45be-9295-5cc443b3be06.jpg"
            }
        })


asyncio.run(main())

curl https://api.runware.ai/v1 \
  -H "Authorization: Bearer $RUNWARE_API_KEY" \
  -H "Content-Type: application/json" \
  -d '[
    {
      "taskType": "controlNetPreprocess",
      "taskUUID": "9fb53589-878c-4443-90bf-061f89931ac1",
      "model": "runware:controlnet-preprocess@canny",
      "settings": {
        "lowThresholdCanny": 80,
        "highThresholdCanny": 190
      },
      "inputs": {
        "image": "https://assets.runware.ai/assets/inputs/fe5e44a9-08e9-45be-9295-5cc443b3be06.jpg"
      }
    }
  ]'

runware run runware:controlnet-preprocess@canny \
  settings.lowThresholdCanny=80 \
  settings.highThresholdCanny=190 \
  inputs.image=https://assets.runware.ai/assets/inputs/fe5e44a9-08e9-45be-9295-5cc443b3be06.jpg

{
  "taskType": "controlNetPreprocess",
  "taskUUID": "9fb53589-878c-4443-90bf-061f89931ac1",
  "model": "runware:controlnet-preprocess@canny",
  "settings": {
    "lowThresholdCanny": 80,
    "highThresholdCanny": 190
  },
  "inputs": {
    "image": "https://assets.runware.ai/assets/inputs/fe5e44a9-08e9-45be-9295-5cc443b3be06.jpg"
  }
}

Response

{
  "taskType": "imageControlNetPreProcess",
  "taskUUID": "9fb53589-878c-4443-90bf-061f89931ac1",
  "guideImageURL": "https://im.runware.ai/image/os/a07dlim3/ws/3/ii/ab9744e7-3c8e-4107-b128-f1956b8d7d32.jpg",
  "cost": 0.0006,
  "guideImageUUID": "ab9744e7-3c8e-4107-b128-f1956b8d7d32",
  "inputImageUUID": "5ae42ec8-2d97-479e-b19c-1d7cf38f6292"
}

Preprocess

Paperfold Dragon Street Sculpture

import { createClient } from '@runware/sdk'

const client = await createClient({ apiKey: process.env.RUNWARE_API_KEY })
await client.connect()

const [result] = await client.run({
  model: 'runware:controlnet-preprocess@canny',
  settings: {
    lowThresholdCanny: 80,
    highThresholdCanny: 190
  },
  inputs: {
    image: 'https://assets.runware.ai/assets/inputs/e6b4790b-9e03-4574-91d1-abf57d6b0c1b.jpg'
  }
})

import asyncio
import os

from runware import Runware


async def main():
    async with Runware(api_key=os.environ["RUNWARE_API_KEY"]) as client:
        results = await client.run({
            "model": "runware:controlnet-preprocess@canny",
            "settings": {
                "lowThresholdCanny": 80,
                "highThresholdCanny": 190
            },
            "inputs": {
                "image": "https://assets.runware.ai/assets/inputs/e6b4790b-9e03-4574-91d1-abf57d6b0c1b.jpg"
            }
        })


asyncio.run(main())

curl https://api.runware.ai/v1 \
  -H "Authorization: Bearer $RUNWARE_API_KEY" \
  -H "Content-Type: application/json" \
  -d '[
    {
      "taskType": "controlNetPreprocess",
      "taskUUID": "963bfadc-61cf-4e50-a90f-2ae9b4ab1cda",
      "model": "runware:controlnet-preprocess@canny",
      "settings": {
        "lowThresholdCanny": 80,
        "highThresholdCanny": 190
      },
      "inputs": {
        "image": "https://assets.runware.ai/assets/inputs/e6b4790b-9e03-4574-91d1-abf57d6b0c1b.jpg"
      }
    }
  ]'

runware run runware:controlnet-preprocess@canny \
  settings.lowThresholdCanny=80 \
  settings.highThresholdCanny=190 \
  inputs.image=https://assets.runware.ai/assets/inputs/e6b4790b-9e03-4574-91d1-abf57d6b0c1b.jpg

{
  "taskType": "controlNetPreprocess",
  "taskUUID": "963bfadc-61cf-4e50-a90f-2ae9b4ab1cda",
  "model": "runware:controlnet-preprocess@canny",
  "settings": {
    "lowThresholdCanny": 80,
    "highThresholdCanny": 190
  },
  "inputs": {
    "image": "https://assets.runware.ai/assets/inputs/e6b4790b-9e03-4574-91d1-abf57d6b0c1b.jpg"
  }
}

Response

{
  "taskType": "imageControlNetPreProcess",
  "taskUUID": "963bfadc-61cf-4e50-a90f-2ae9b4ab1cda",
  "guideImageURL": "https://im.runware.ai/image/os/a06dlim3/ws/3/ii/28acbf79-ad81-437b-86e3-974fee8158e4.jpg",
  "cost": 0.0006,
  "guideImageUUID": "28acbf79-ad81-437b-86e3-974fee8158e4",
  "inputImageUUID": "8e42795e-f465-4719-9931-ebc4e7b1efc8"
}
